ANSI requirements for self-retracting fall protection

ANSI requirements
October 1, 2016
Marty Sharp
KEYWORDS American National Standards Institute / Fall Protection / self-retracting lifeline / work at height
Reprints

I was probably eight to ten years of age when I first learned that gem of wisdom: Let the buyer beware. I look around today and I don’t see much evidence that buyers are aware of that truth. A cursory look at a product’s specs and a quick check of the price and, bang, the purchase is complete.

 However the wisdom of “let the buyer beware” still holds true. In our own industry, fall protection, I think about buying retractable lanyards. ANSI has established two classes of retractables to protect life. As a buyer you need to understand the difference. It is truly a matter of life and death.

Let’s examine the standard. The latest ANSI standard relating to this device is ANSI Z359.14-2012, “safety requirements for self-retracting devices.” This standard supersedes the requirements found in ANSI Z359.1 and Z 359.4.

Major points & changes in the new standard

1. Scope, purpose, application, exceptions and interpretations

 1.1 Scope. This standard specifies requirements for qualification and verification testing of ANSI/ASSE Z359, Fall Protection Code, products. It includes requirements for third-party testing, witness testing and manufacturer testing of fall protection products to the requirements of the ANSI/ASSE Z359 standards.

 1.2 New Terms: SRD, SRL-R, SRL-LE

— SRD – Self Retracting Devices, includes SRL’s, SRL-R’s and SRL-LE’s

— SRL – Self Retracting Lanyard (or Self Retracting Lifeline)

— SRL-R – SRL with integral rescue capabilities

— SRL-LE with leading edge capability.

 1.3 Self –Retracting Device Classifications. Self-retracting devices shall be classified according to dynamic performance as follows:

 Class A: Maximum arrest distance of 24 inches (610mm).

 Class B: Maximum arrest distance of 54 inches (1,372mm).

In addition to a maximum arrest distance of 24” Class A, must have an average arresting force not to exceed 1,350 pounds. Class B must have an average arresting force not to exceed 900 pounds.

Visual indicator

SRDs shall include a visual fall indicator. Typically this is built into the snap hook or area near the snap hook. The fall indicator helps provide a positive indication of a fall. External energy absorbers may also be utilized as visual indicators.

Leading edge

For the first time, a leading edge test for SRDs is included in the standard. Specific test criteria must be met in order for devices to be labeled for leading edge work (where the lifeline can come in contact with a sharp edge during fall arrest). Devices meeting these requirements are designated SRL-LE. Leading edge rated devices will have specific information both on the label and in the instruction manual provided by the manufacturer.  It’s interesting to note that for the dynamic testing of SRL-LE devices, the material used for the edge test shall be 3/8 x 3 inch or larger size 1018 cold finished steel bar in accordance with ASTM.A108. See paragraph 4.1.10 in the standard.

Inspection

 New inspection requirements are included. The frequency of inspection by a competent person, and factory authorized inspections is determined by usage. As the user, you must conduct an eight-point inspection of your SRD before each use:

— Ensure the safety retractable locks when the lifeline is pulled sharply, with no slippage. Lock-up should be positive.

— Labels must be present and fully legible.

— Check the connecting hooks or carabiners for damage, distortion, or corrosion, and working condition.

— Check the housing for distortion, cracks, or other damage and make sure anchorage point is not distorted or damaged.

— Inspect each component of the personal fall protection system according to the manufacturer’s instructions.

— The lifeline must fully extend and retract smoothly with no hesitation or slack on the line.

— Check the lifeline for cuts, burns, chemical damage, abrasions, loose strands, or corrosion, the lifeline must not be damaged.

— Check for loose or missing screws and bent or damaged parts.

 After a fall, equipment that has been subjected to fall arrest forces must be removed from service for inspection.

Testing & labeling

 All required tests must be performed in accordance with the standard and by a laboratory which satisfies the requirements of the standard.

 Although self-testing is acceptable providing the above conditions are met, true third-party testing is desirable. Manufacturers may not claim compliance with portions or segments of the requirements. Products should be labeled as being compliant with the standard.

Self-retracting devices shall be marked to identify:

— Part number and model designation;

— year of manufacture;

— manufacturer’s name or logo;

— capacity range;

— unique ID number;

— standard number (Z359.14);

— how to inspect visual indicator;

— warning to follow the manufacturer’s instructions included with the equipment at time of shipment from the manufacturer;

— warning of the need for inspection in accordance with the manufacturer’s instructions;

— the fiber or other materials used in the lanyard construction;

— the lanyard working length;

— average arresting force for the SRD class;

— arrest distance;

— proper installation means;

— warning of the need for testing of the device for locking and retraction before each use;

— SRD class;

— warning of the need to avoid lanyard contact with sharp edges and abrasive surfaces (not required for leading edge type SRD’s);

— free fall limit;

— suitability for use with horizontal lifelines;

— suitability for horizontal use.

Which SRD is needed for your application?

 Class “A” SRDs should be used only when the tie-off is overhead, the free fall is limited to 24 inches and there is no possibility of falling over a leading edge. In reality, this is very few situations.

 Class “B” SRL-LE should be used for all other applications. The “LE” has a freefall of 54 inches and is approved for tie-off overhead or at foot level, horizontal installation and of course falls over leading edges.

Subscribe to ISHN Magazine

Recent Articles by Marty Sharp

Training and reading equipment instructions can save lives

Training and reading equipment instructions can save lives

Fall protection frustration

Preventing falls & arc flash burns

Marty Sharp is president of Arizona Wire & Rope and Ultra-Safe Inc. In the industry for more than 25 years, he is a respected hands-on fall protection leader. Ultra-Safe Inc. services include planning and training. Call Marty at 800-850-5914 or email marty@ultrasafeusa.com.
